1. 전기적 측정 사양 (Measurement Specifications)
| 측정 항목 (Function) | 측정 범위 (Range) | 정확도 (Accuracy) |
|---|---|---|
| 직류 전압 (DC Voltage) | 600.0 V | ±(0.5 % of reading + 5 digits) |
| 교류 전압 (AC Voltage) (50 Hz ... 3.1 kHz) |
600.0 V | ±(0.5 % of reading + 5 digits) ... ±(2.5 % of reading + 5 digits) |
| 교류 전류 (AC Current) (40 Hz ... 3.1 kHz) |
40.00 A ... 600 A | ±(1.0 % of reading + 5 digits) ... ±(3.0 % of reading + 5 digits) |
| 저항 (Resistance) | 999.9 Ω | ±(1.0 % of reading + 6 digits) |
| 피상전력 (Apparent Power) | 0 kVA ... 600.0 kVA |
±(2.0 % of reading + 6 digits) (H: 1/10) ±(3.5 % of reading + 6 digits) (H: 11/46) ±(5.5 % of reading + 6 digits) (H: 46/51) |
| 유효전력 / 무효전력 (Active / Reactive Power) |
0 kVA ... 600.0 kW, kVar |
±(2.0 % ~ 10.0 % of reading + 6 digits) (H: 1/10) ±(3.5 % ~ 10.0 % of reading + 6 digits) (H: 11/25) ±(4.5 % ~ 15.0 % of reading + 6 digits) (H: 26/45) ±(10.0 % ~ 15.0 % of reading + 6 digits) (H: 46/51) |
| 역률 (Power Factor - PF) | 0.10 ... 0.99 |
±3 digits (고조파 H: 1/21) ±5 digits (고조파 H: 22/51) |
| 전원 주파수 (Mains Frequency) | 5 Hz ... 500 Hz | ±(0.5 % of reading + 4 digits) |
2. 일반 사양 (General Specifications)
| 측정 범주 (Overvoltage Category) | CAT IV / 300 V ; CAT III / 600 V |
| 전원 공급 (Power Supply) | 1.5V AAA 규격 배터리 2개 |
| 외형 치수 (Dimensions) | 189 x 78 x 40 mm |
| 무게 (Weight) | 192 g |
-
