  • 제품 분류별
  • LCR미터

LCR미터

LCR METER

40Hz to 200kHz LCR 미터

  • ±0.05% accuracy with wide measurement range
  • Non-stop testing over mixed measurement conditions such as C-D and ESR
  • Built-in comparator and BIN functions
제조사
HIOKI
제품명
LCR METER
제품번호
IM3523

● ±0.05% accuracy with wide measurement range

(DC, 40Hz to 200kHz, 5mV to 5V, 10uA to 50mA)

● Non-stop testing over mixed measurement conditions such as C-D and ESR at 10 times the speed of previous models (compared with Model 3532-50)

● Built-in comparator and BIN functions

● Rapid 2msec test time
