저항테스터

저저항계

◾High or low output power selection for condition diagnosis

  • 최대 출력 25W
  • IP65 등급으로 열악한 현장환경에 적합
  • 0 to 2,500.0Ω 측정가능
제조사
MEGGER
제품명
저저항계
제품번호
DLRO10HD
  • High or low output power selection for condition diagnosis
  • Rechargeable battery or line power supply, continuous operation, even with dead battery
  • 10 A for 60 seconds, less time waiting to cool, great for charging inductance
  • High input protection to 600 V, inadvertent connection to line or UPS voltage will not blow a fuse
  • Heavy duty case: IP 65 lid closed, IP54 operational (battery operation only)
  • Rotary switch selects one of five test modes, including auto start on connection, giving ease of use
  • Equally at home in the laboratory, the workshop or in the field, on the bench or on the ground, The heavy duty Megger Ducter™ DLRO10HD low resistance ohmmeter combines rugged construction with accuracy and ease of use.

    It features an internal rechargeable battery and can also operate from a mains supply, even if the battery is completely flat.

    History of ‘Ducter’ testing
    For over 100 years the ‘Ducter test’ has been used to describe a simple test for measuring very low contact resistances and “Ducter”, which is still used as a trade mark, was the name originally given to the low resistance ohmmeter manufactured by Megger.

    The name Ducter was registered by Megger in June 1908 and ‘Ducter’ has since become the industry standard.



    - 최대 출력 25W
    - AC전원 및 배터리 겸용
    - IP65 등급으로 열악한 현장환경에 적합
    - 0 to 2,500.0Ω 측정가능
    - 작동모드 : High or Low Power출력
    - 이동이 용이한 내부배터리 사용
    - 사용자요구에 맞는 리드선 선택가능
